Before installation, plan the cable tray route based on your site layout, cable type, and load requirements. Consider clearance from other services, future expansion, and environmental conditions. Mark the path using a chalk line or laser level to ensure straight, level alignment for wall-mounted or ceiling-suspended trays .
Choose a tray type suitable for large or heavy cables like 185-type. Ladder trays are preferred for high-capacity cables because they provide ventilation, heat dissipation, and easy cable entry. Perforated or solid-bottom trays may be used for lighter loads or where aesthetics and protection are priorities . Material selection (galvanized steel, aluminum, or fiberglass) should match environmental conditions to prevent corrosion .
Calculate the tray width and depth based on the number of 185-type cables and their cross-sectional area. Use NEC Table 392.22(A) or manufacturer specifications to determine maximum fill. Ensure the total cable area does not exceed the tray's rated capacity, and consider ampacity derating for high-density fills . Maintain proper spacing between cables to prevent overheating.
Install supports at regular intervals, typically 1.5 to 3 meters depending on tray type and load. Wall-mounted trays use cantilever brackets, while ceiling trays use trapeze or C-hanger systems with threaded rods and Unistrut channels . Ensure all supports are level and secure to prevent sagging.
Lay cables neatly, using cable ties or straps to organize by voltage or function. Maintain the minimum bend radius for 185-type cables to avoid damage. Use rollers or sheaves for long runs to prevent kinks and abrasion . Plan bends, tees, and risers carefully to maintain smooth cable paths.
For metal trays, bond and ground all sections to maintain electrical continuity and safety. Use proper bonding jumpers across tray sections and ensure compliance with NEC or local electrical codes .
