Lay a grounding wire next to the cable tray

A grounding wire should be installed parallel to the cable tray, securely connected to the tray and the facility's grounding system to ensure safety and system reliability.

Purpose of Grounding

Grounding a cable tray provides a low-impedance path for fault currents, protecting personnel and equipment from electric shocks, overvoltage, and fire hazards. It also helps dissipate lightning energy, reduce electromagnetic interference (EMI), and improve overall system stability and reliability .

Placement and Installation

• Parallel Routing: The grounding wire should run parallel to the cable tray, maintaining close proximity without touching flammable or corrosive materials .
• Connection Points: Secure the wire to the tray at regular intervals using grounding clamps, lugs, or plated connectors. For metal trays, remove insulation at bonding points to ensure a solid electrical connection .
• Continuous Path: For maximum safety, use a continuous grounding conductor along the tray's length, or bond the tray sections alternately to maintain electrical continuity .
• Material Selection: Use copper, hot-dip galvanized steel, or stainless steel for the grounding wire, depending on environmental conditions and corrosion resistance requirements .
• Avoid Bare Copper in Aluminum Trays: If using aluminum trays, avoid bare copper to prevent electrolytic corrosion; instead, use insulated conductors with exposed ends at bonding points .

Compliance and Safety

• Ensure the grounding system meets local and international electrical standards, including NEC requirements for cable tray grounding and bonding .
• Maintain low grounding resistance, ideally 4 ohms or less, to ensure effective fault current diversion .
• For critical installations, such as industrial or rail systems, consider independent grounding lines with appropriate cross-section conductors and grounding terminals .

Additional Considerations

• Tray as Grounding Conductor: In some cases, metal trays can serve as the grounding path if they meet conductivity and mechanical strength requirements, but a separate wire is often recommended for reliability .
• Maintenance: Regularly inspect grounding connections for corrosion, looseness, or damage to maintain system integrity . By following these practices, the grounding wire will provide a safe, reliable, and code-compliant path for fault currents, enhancing both personnel safety and equipment protection.
