Power Parameter Table for Secondary Distribution Box
A secondary distribution box typically operates at low voltage (e.g., 400/230 V), with rated currents and protection devices selected based on transformer capacity and load requirements.
Typical Power Parameters
| Parameter | Typical Value / Range | Notes |
|---|---|---|
| Secondary Voltage | 400/230 V (three-phase/line-to-neutral) | Standard low-voltage distribution for commercial/residential loads |
| Rated Current (In) | 100 A – 400 A | Depends on transformer rating and connected load |
| Short-Circuit Rating (Isc) | 10 kA – 25 kA | Must match upstream protection and cable ratings |
| Transformer Capacity | 50 kVA – 500 kVA | Secondary distribution box is fed from distribution transformer |
| Protection Devices | MCCB, MCB, fuses | Selected for overload, short-circuit, and earth-fault protection |
| Busbar Material | Copper or Aluminum | Sized according to rated current and thermal limits |
| Neutral Conductor | Sized for unbalanced load | Typically same cross-section as phase conductors for high reliability |
| Earthing / Grounding | TN-S, TN-C-S, or TT | Ensures safety and compliance with local codes |
| Voltage Drop | ≤ 3–5% | Calculated based on cable length and load to maintain voltage quality |
| Ambient Temperature Rating | 30–40 °C | Adjust derating factors for higher temperatures |
Design Considerations
- Load Assessment: Determine maximum connected load and diversity factor to size the secondary distribution box and select protective devices .
- Short-Circuit Coordination: Ensure that upstream and downstream protection devices are coordinated to isolate faults without affecting the entire network .
- Transformer Selection: The secondary distribution box must match the transformer's secondary voltage and rated current, considering future load growth .
- Cable Sizing: Conductors must be sized for rated current, voltage drop, and short-circuit withstand capability .
- Safety Compliance: Follow NEC, IEC, or local electrical codes for installation, grounding, and protection . This table and guidelines provide a practical reference for engineers and electricians designing or specifying secondary distribution boxes in low-voltage networks, ensuring safe and reliable operation while meeting regulatory standards.
