Cable tray elbow types and specifications table
Cable tray elbows are specified by type, bend angle, tray width, material, finish, and radius of curvature to ensure proper cable routing and mechanical support.
Key Specifications for Cable Tray Elbows
Cable tray elbows are used to change the direction of cable runs and are available in horizontal and vertical configurations, including inside and outside bends. Standard specifications typically include:
| Parameter | Typical Values / Notes |
|---|---|
| Bend Type | Horizontal 90°, Horizontal 45°, Vertical Inside, Vertical Outside |
| Tray Width Compatibility | 50 mm, 75 mm, 100 mm, 150 mm, 200 mm, 300 mm, 400 mm, 600 mm |
| Tray Height (H) | 50 mm, 70 mm, 100 mm, 120 mm (varies by manufacturer) |
| Material | Steel (hot-dip galvanized, pre-galvanized, bare), Stainless Steel (AISI 304, 316L), Aluminum |
| Finish / Coating | Hot-dip galvanized, pre-galvanized, powder-coated, bare metal |
| Bend Radius | Typically 1–2 times the tray width for ladder or ventilated trays; solid trays may require larger radii to prevent cable damage |
| Standards Compliance | ANSI/NFPA 70 (NEC), NEMA VE 1 & VE 2, ASTM A123, A653, A1011, A1008, B633 |
| Load Rating | Determined by tray type, material, and span; consult manufacturer's safe working load tables |
| Accessories | Integral side lugs, splice plates, fast-fit connectors (e.g., Swiftclip, Swiftgrip) for secure assembly |
Additional Considerations
- Adjustable Elbows: Some systems allow adjustable angles in 5° increments to accommodate field conditions.
- Installation: Elbows should maintain the minimum bend radius for cables to prevent stress or insulation damage.
- Environmental Factors: Material and finish selection should consider corrosion resistance, especially in outdoor or industrial environments. Stainless steel (316L) is preferred in highly corrosive areas, while galvanized steel is common for general use.
- Compatibility: Ensure elbows match the tray type (ladder, ventilated, solid bottom, or channel) and width to maintain structural integrity and cable support. These specifications are consistent with technical guides from Legrand, Eaton, and ABB, which provide detailed tables for elbow dimensions, materials, and installation guidelines to ensure compliance with electrical codes and mechanical safety requirements .
